    Cobot Industrial Collaborative MIG Welding Machine For Welding Thick Iron Plates

    Ask Lasest Price
    Brand Name : TAIYI
    Model Number : TY-HS6018
    Certification : CE
    Price : Contact us for the price
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 200 Sets/month
    Delivery Time : 15-30 work days
    • Product Details
    • Company Profile

    Cobot Industrial Collaborative MIG Welding Machine For Welding Thick Iron Plates

    Cobot Industrial Collaborative MIG Welding Machine For Welding Thick Iron Plates



    TECHNICAL GUIDANCE FOR ONTOLOGY

    Robotic Arm Parameters


    MaxArmspan

    1077mm

    Payload

    7kg

    Repeat Positioning

    ±0.02mm

    ToolMax speed

    3000mm/s

    ControlBus/Freq

    EtherCAT/1KHz

    Rated power

    260W

    Temperature

    -5~55℃

    Humidity

    5%~90%RH,non-condensing

    Installation mode

    Arbitrary angle

    Protection Degree

    IP65

    weight

    21kg

    Noise level

    ≤60dB

    Work port

    1/0 Port

    24V/18;DI:2D0:2AI

    Tool Pot

    COM Port

    24V/1A;1RS485:1 EtherCAT

    Joint Movement Parameters

    Iotion Range

    J1

    -360°“360°

    J2

    -360°"360°

    J3

    -165°“165°

    J4

    -360°"360°

    J5

    -360°360°

    J6

    -360°“360°

    Max Speed

    J1

    210°s

    J2

    210/s

    J3

    210°/s

    J4

    360°/s

    J5

    360°/s

    J6

    360°/s
